SD-WAN: Secure, High-Performance, Simple
Easily adopt an end-to-end SD-WAN architecture with natively integrated, world-class security and connectivity


Palo Alto Networks SD-WAN

The effects of the cloud on network and security transformation are undeniable. As the number of devices at branch locations grows and applications become more bandwidth-intensive, businesses are forced to spend more to accommodate demand. As a result, traditional wide area network (WAN) architectures with multiprotocol label switching (MPLS), which tend to eat up bandwidth as they backhaul traffic from branches to the cloud, render legacy approaches ineffective.

Software-defined wide area networking (SD-WAN), an approach that uses commodity links and allows you to intelligently manage as well as control connectivity between branches and cloud instances, is now a necessity for distributed enterprises. According to Gartner, by 2023, more than 90% of WAN edge infrastructure refreshes will be based on vCPE platforms or SD-WAN vs. traditional routers.1 However, with its benefits, SD-WAN also brings many challenges, such as lack of security, unreliable performance, and complexity. When security is an afterthought, it tends to be either subpar or bolted on, introducing management complexity. Moreover, network performance becomes less reliable because enterprises use the congested internet as the WAN middle mile—and when they try to address this by building their own SD-WAN hub infrastructures, they run into complexity. Ultimately, enterprises turn to multiple vendors or service providers to solve performance issues, which increases costs while decreasing control and visibility.

Benefits

Secure Branch Connectivity Directly from Your Firewall

Solve the problems of traditional SD-WAN solutions with industry-leading:

icon-security

Security

Get industry-leading security natively integrated to SD-WAN.

icon-Performance

Performance

Minimize latency and ensure reliability to deliver exceptional end-user experience.

icon-Simplicity

Simplicity

Easily enable SD-WAN on your existing firewalls.

Secure SD-WAN by Palo Alto Networks

Palo Alto Networks SD-WAN offering lets you easily adopt an end-to-end SDWAN architecture with natively integrated, world-class security and connectivity. Using Prisma™ Access as the SD-WAN hub, you can optimize the performance of your entire network. This minimizes latency and ensures reliability, resulting in an exceptional user experience at the branches. You can consume our secure Prisma Access SD-WAN hub as a service, eliminating the complexity of building your SDWAN hub infrastructure, or you can build the hub and interconnect infrastructure yourself using Palo Alto Networks Next-Generation Firewalls. Regardless of your deployment model, our tight integration will allow you to manage security and SD-WAN on a single, intuitive interface.

 Palo Alto Networks SD-WAN cloud-based approach

Figure 1: Palo Alto Networks SD-WAN cloud-based approach

Optimized Connectivity for Improved User Experience

Palo Alto Networks SD-WAN lets you measure and monitor specific paths as well as dynamically move sessions to the optimal path, guaranteeing the best branch user experience. You can simply enable the SD-WAN subscription on your Next-Generation Firewalls and begin intelligently, securely routing branch traffic to your cloud applications.

Greater Performance with SD-WAN Hub

SD-WAN leverages commodity links, such as broadband internet, LTE, and more. However, while these links are cost-effective, they lack the reliable performance of dedicated, private links.

With Prisma Access acting as the SD-WAN hub, users can essentially go through a private network, bypassing the congested, unpredictable internet. By using a reliable, cloud native global backbone as your WAN middle mile, you ensure the best performance and user experience.

Central Management for Security and Connectivity

Eliminate the need to manage multiple, disparate consoles from different vendors by using Panorama™ network security management for both security and connectivity. Integrated SD-WAN configuration and monitoring allows you to leverage the familiar Panorama user and application workflow, cutting the time you need to spend reconfiguring policies and visualizations. Additionally, you get granular SD-WAN monitoring data and a dedicated configuration tree, giving you greater visibility into your network.

Simplified Branch Onboarding

Provisioning a new branch requires IT staff to configure and deploy appliances. Doing this on a large scale, and at distributed locations, makes branch onboarding costly and slow.

With zero touch provisioning (ZTP), you can automate tedious onboarding processes. Appliances can be drop-shipped to your branch locations, where they are powered up and connected to the internet. To complete onboarding, administrators simply need to register on a web portal. Then, administrators can immediately start managing deployment and configuration from a single location through Panorama.

Flexible Deployment Options

Palo Alto Networks supports multiple SD-WAN deployment options, including mesh, hub-and-spoke, and cloud-based deployments. Furthermore, you can consume Prisma Access SD-WAN hub as a service or simply enable the SD-WAN subscription on your Next-Generation Firewalls.

SD-WAN Software Licenses

  • (Required) SD-WAN subscription on all physical appliances that will participate in the SD-WAN deployment. This license requires PAN-OS® 9.1.
  • (Required to use Prisma Access for SD-WAN hub) Prisma Access SD-WAN Branch Interconnect license.
Table 1: Palo Alto Networks SD-WAN Supported Features and Capabilities
Category Features
AAA/Authentication RADIUS, local authentication and authorization, multitenant 3-tier RBAC architecture, auditing, roles and privileges
Availability Hardware high availability in active/passive mode
SD-WAN features
  • Link metric collection, jitter, drop, delay
  • Intelligent path selection based on metric; dynamic application steering
  • Application and network condition aware sub-second steering
  • Session-based link aggregation
  • Scalable bidirectional path health measurements, QoS, traffic shaping
  • Predefined application thresholds for common application categories
  • Forward error correction (FEC)
  • Packet duplication
  • SaaS application path monitoring: end-to-end application monitoring from the branch to the SaaS app server
Network services IPv4, DNS, DHCP client, DHCP server, DHCP relay, NAT
Dynamic QoS/traffic shaping QoS shaping, policing, and rate limiting with per-flow queueing and separate cleartext and tunnel treatment. Support for 8 queues, type of service (ToS) and DSCP code points with patented bidirectional session-based DSCP tagging
Routing
  • Static routes
  • OSPF
  • BGP
    • Local route ID and local AS, path selection, BGP confederations, route flap dampening, graceful restart, IGP-BGP route injection
    • Route import, export, and advertisement; prefix-based filtering; address aggregation
  • Multiple virtual routers
  • Authentication by MD5
SD-WAN high availability Active/passive HA; dual power supply
Connectivity architecture Hub-and-spoke IPsec tunnels with automatic configuration
Management Single pane of glass for security and SD-WAN management
  • Panorama-managed, API, syslog, SNMP
  • RBAC
  • Scale up to 5,000 devices per Panorama
  • Zero touch provisioning (ZTP)*
  • Monitoring and visualization
  • Dashboard views of SD-WAN impacted applications and links with drill down
  • SD-WAN link down alerts to detect blackout situations
  • SD-WAN reporting
  • Link jitter, delay, and drop trend charts
Deployment flexibility
  • Physical and virtualized Next-Generation Firewalls for both branch and hub
  • Hub-and-spoke
  • Mesh
  • Cloud-based with Prisma Access
* Coming soon with new SKUs
Coming soon
Table 2: SD-WAN Edge Device Specifications
  PA-220 PA-220R PA-820 PA-850
Branch office bandwidth
(recommended range)
1–150 Mbps 1–150 Mbps 50–500 Mbps 50–700 Mbps
Max. overlay IPsec tunnels 1K 1K 1K 1K
Max. concurrent sessions 64K 64K 128K 196K
Max. number of routes 2.5K 2.5K 5K 5K
Connectivity Options
LAN/WAN 1G RJ-45 8 6 4 4
LAN/WAN 1G SFP 2 8 4
LAN/WAN 1G/10G SFP 4
LAN/WAN 40G QSFP
Serial console port
USB console port
Management port
1 1 1 1
HA - dual power input Optional Optional No Yes
Any box can be used as a hub or branch
Table 3: SD-WAN Hub Device Specifications
  PA-3220 PA-3250 PA-3260 PA-5220 PA-5250 PA-5260 PA-5280 VM-300 VM-500 VM-700
IPsec overlay performance with App-ID 2.0 Gbps 2.3 Gbps 3.5 Gbps 7.4 Gbps 15.2 Gbps 21.8 Gbps 21.8 Gbps 1.8 Gbps 4 Gbps 6.1 Gbps
Max. overlay IPsec tunnels 2K 3K 3K 3K 4K 5K 5K 1K 1K 8K
Max. concurrent sessions 1M 2M 3M 4M 8M 32M 32M 819,200 2M 10M
Max. number of routes 16K 16K 44K 100K 100K 100K 100K 10K 32K 100K
Connectivity Options
LAN/WAN 1G/10G SFP 8 8 8 16 16 16 16
LAN/WAN 40/100G QSFP28 4 4 (40G only) 4 4 4
Serial console port
Management port
1 1 1 1 1 1 1
HA - dual power input Optional Optional Optional Yes Yes Yes Yes

To compare performance and specifications for all our firewall offerings, visit paloaltonetworks.com/products/product-selection.
