Palo Alto Networks Business Products and Solutions
Enterprise Security Platforms

Next-Generation Firewall Appliances

PA-220 Firewall

500 Mbps firewall throughput (App-ID enabled)
150 Mbps threat prevention throughput
100 Mbps IPSec VPN throughput
64,000 max sessions
4,200 new sessions per second

PA-820 Firewall

940 Mbps firewall throughput (App-ID enabled)
610 Mbps threat prevention throughput
400 Mbps IPSec VPN throughput
128,000 max sessions
8,300 new sessions per second

PA-850 Firewall

1.9 Gbps firewall throughput (App-ID enabled)
780 Mbps threat prevention throughput
400 Mbps IPSec VPN throughput
192,000 max sessions
9,500 new sessions per second

PA-3020 Firewall

2 Gbps firewall throughput (App-ID enabled)
1 Gbps threat prevention throughput
500 Mbps IPSec VPN throughput
250,000 max sessions
50,000 new sessions per second

PA-3050 Firewall

4 Gbps firewall throughput (App-ID enabled)
2 Gbps threat prevention throughput
500 Mbps IPSec VPN throughput
500,000 max sessions
50,000 new sessions per second

PA-3060 Firewall

4 Gbps firewall throughput (App-ID enabled)
2 Gbps threat prevention throughput
500 Mbps IPSec VPN throughput
500,000 max sessions
50,000 new sessions per second

PA-5020 Firewall

5 Gbps firewall throughput (App-ID enabled)
2 Gbps threat prevention throughput
2 Gbps IPSec VPN throughput
1,000,000 max sessions
120,000 new sessions per second

PA-5050 Firewall

10 Gbps firewall throughput (App-ID enabled)
5 Gbps threat prevention throughput
4 Gbps IPSec VPN throughput
2,000,000 max sessions
120,000 new sessions per second

PA-5060 Firewall

20 Gbps firewall throughput (App-ID enabled)
10 Gbps threat prevention throughput
4 Gbps IPSec VPN throughput
4,000,000 max sessions
120,000 new sessions per second

PA-5220 Firewall

18.5 Gbps firewall throughput (App-ID enabled)
9.2 Gbps threat prevention throughput
5 Gbps IPSec VPN throughput
4,000,000 max sessions
169,000 new sessions per second

PA-5250 Firewall

35.9 Gbps firewall throughput (App-ID enabled)
20.4 Gbps threat prevention throughput
14 Gbps IPSec VPN throughput
8,000,000 max sessions
348,000 new sessions per second

PA-5260 Firewall

72.3 Gbps firewall throughput (App-ID enabled)
30.2 Gbps threat prevention throughput
21 Gbps IPSec VPN throughput
32,000,000 max sessions
458,000 new sessions per second

PA-7050 Firewall

120 Gbps firewall throughput (App-ID enabled)
60 Gbps threat prevention throughput
24 Gbps IPSec VPN throughput
24,000,000 max sessions
720,000 new sessions per second

PA-7080 Firewall

200 Gbps firewall throughput (App-ID enabled)
100 Gbps threat prevention throughput
80 Gbps IPSec VPN throughput
1,200,000 max sessions
80,000,000 new sessions per second
225 virtual routers
25/225 virtual systems (base/max)
900 security zones
